Kit for cyclone oil separators FP-OS-80(200)-318(418)F | News

Kit for cyclone oil separators FP-OS-80(200)-318(418)F: heater, thermostat, level sensor, security group
Russian plant components of the refrigeration Frigopoint announces kit for cyclone oil separators FP-OS-80(200) type A. the kit includes electric heating elements, the thermostat, the lower level sensor, diverter valve and relief valve group safety valve Rotalock port for oil return. Kit for oil separators are not included in the standard supply and oil separator is an option that is available on request.

Name	Designation
Low-level sensor (~230V, load capacity up to 8 (2) A, incl. adapter)	FP-ELS+CE
Ten (~230V, 150W, 250 mm long without the cartridge)	FP-TEH-250-150W
Thermostat (6...90°C, load up to 10(AC15 - 2.5 A) A)	FP-TS-90
Valve diverter (port 1 ¼ ” UN , 2 port 3/8” NPT)	FP-TV-114-038
Safety valve FP-SV-038	FP-SV-038
Rotalock valve (for port oil return FP-OS-80)	FP-RV-134-158
Rotalock valve (for port oil return FP-OS-200)	FP-RV-214-218

Standard cyclone oil separators include:
- FP-OS-80-318 / FP-OS-200-418 - sight glass with nut and gasket on the port before.valve (without a cap), the pipe for welding.
- FP-OS-80-318 / FP-OS-200-418 - sight glass with nut and gasket on the port before.valve (without a cap), Flanges without mates.
