- Pressure Vessels
- Receiver station
Oil filters are disposable
FRIGOPOINT oil filters are compatible with all types of refrigerants and refrigeration oils. Fine-meshed filter element is a steel net. The magnitude of delayed particles - more than 0.05 mm.
Application of two niobium magnets can be used for filters filtering the oil flow in two directions. Installed in the filter magnets allow delay metal magnetizable particles substantially smaller than the mesh filter catches.
Thus, oil filters FRIGOPOINT efficiently purified oil extending the useful life of the refrigeration unit.
|Model||Connector||Size of captured particles, mkm||Niobium magnets||Working pressure, MPa||Testing pressure, MPa|
|FP-OF-058||7/8"-14 UNF (5/8"SAE)||> 50 мкм||+||2,8||3,5|
|FP-OF-014||7/16"-20UNF(1/4"SAE)||> 50 мкм||+||2,8||3,5|
|FP-OF-038||5/8"-18 UNF (3/8"SAE)||> 50 мкм||+||2,8||3,5|
|FP-OF-012||3/4"-16 UNF (1/2"SAE)||> 50 мкм||+||2,8||3,5|
